Handheld Potentiostat/Galvanostat, Electrochemical Analyzer (MedPstat 2.0 Advance)

Original price was: $3,100.00.Current price is: $2,990.00.

  • Handheld Affordable & Potentiostat/Galvanostat
  • Applied Potential Range: ± 10 V
  • Max Current Range: 250 mA
  • Measured Potential Range (Gal): ±10 V
  • USB Communication
  • Software for PC Data acquisition & plotting

MedPstat 2.0 Advance is a Portable, Affordable, & Precision Potentiostat/Galvanostat with a wide range of ± 10V, 250 mA. Optimum for electrochemistry research applications. Included is a high-quality dummy cell for learning & calibration applications and lifetime access to free software - MedEplot for PC, data acquisition & plotting.

Detailed Specifications:

  • Electrochemical Methods: CV, LSV, ChronoAmp, OCP, DPV, SWV, ChronoPot, Charge-Discharge, Corrosion Analysis (Tafel), Corrosion Analysis (Polarization Resistances)
  • Channels Per Unit: 1
  • Applied potential range: ± 10 V
  • Applied Potential Accuracy: 0.1% of the setpoint, 1mV Max
  • Applied Potential Resolution: 152 µV
  • Measured Potential Accuracy: 0.1% of the setpoint, 1mV Max
  • Measured Potential Resolution: 156 µV
  • Compliance Voltage: ±15 V
  • Maximum Current: 250 mA
  • Current ranges: 7 Ranges (100nA to 250mA)
  • Measured Current Accuracy: 0.5% of the range, 50pA max
  • Measured Current Resolution: 0.015% of range, 1.5 pA
  • Applied Current Resolution (Gal): 1.52 nA
  • Measured Potential Range (Gal): ±10 V
  • Input Impedance: > 10 TΩ
  • Input Bias Current: 1pA Max
  • Computer Interface: USB
  • Channel Cable Length: 0.8 meters
  • power supply: 24V DC
  • Power Supply Requirements: 100V - 240V AC
  • Weight: 320 grams
  • Physical Dimensions: 181mm * 91.5mm * 42mm
  • Operating temperature range: 0 to 50°C
  • Communication: USB
  • PC Software: Available with a lifetime license
  • Bandwidth: up to 4 MHz
  • Max. data acquisition rate: 1 KHz
  • ADC/DAC Resolution: 16 bit
  • Slew Rate (No Load): 45V/µs
  • Maximum ADC Sampling Speed: 5,00,000 samples/sec

Additional information

Weight 1.4 kg
Dimensions 340 × 300 × 90 cm
Select Model

MedPstat 1.0 (Basic) 30mA, MedPstat 1.0 (Advance) 100mA, MedPstat 1.0 (EC Kit) with Cell Setup

Software

MedPstat comes with lifetime free licensed version of MedEplot data acquisition & plotting software. It is compatible with any PC or laptop with windows OS.
MedEplot is specifically designed to

Simple User Interface

Light Weight Software

Live Data View

Save Data in CSV

Open / Overlay Plot

Windows / IOs

MedPstat 2.0 Kit Package

MedPstat 2.0

Most Versatile Potentiostat/Galvanostat (1 piece)

Electrode Cable (1 Piece)
Mini Dummy Cell (1 piece)
Power Adaptor (1 piece)
USB C Cable (1 piece)
Pen Drive with Software (1 piece)
Warranty: 1 Year

Offer Price: $1999
